Glass Reinforced Polyester Pipe & Fittings

Glass Reinforced Polyester Pipe & Fittings

Superlit is a flexible glass reinforced polyester (GRP) pipe system suitable for pressure and non pressure water supply, wastewater and industrial applications.

GRP pipe and fittings are manufactured using three composite raw materials: glass fibre, sand and thermosetting resins. Through an advanced manufacturing process, GRP pipe offers the required pressure rating, structural strength, stiffness rating, and abrasion resistance.

  • Extensive inventory available for immediate delivery

  • Suitable for water, wastewater and industrial applications up to PN40

  • Lightweight, corrosion resistant and simple to install

  • Innovative full face EPDM coupling system

  • 100+ year expected design life

  • No sleeving, coatings or cathodic protection required

Overview

GRP is highly chemical resistant and suitable for aggressive environments such as acid sulphate soils. GRP is a well-established pipe material that is suitable for the most corrosive of fluids, making it an ideal option for wastewater mains, drainage and waste fluids.

With a fully integrated rubber ring joint, it is especially effective in projects that require large diameters, high pressures, deep burial application, or all three in combination.

We ensure each product is accredited to Australian standards, with our GRP pipe and fittings certified to AS3571.

We offer GRP products that are produced using either the Continuous Filament Winding (CFW) or Centrifugal Casting (CC) manufacturing process.Typically, the CFW process leads to a more material efficient pressure pipe, ideally suited to high pressure applications such as water mains and sewer rising mains.

Alternatively, the CC process produces a pipe that is equipped with qualities for dealing with higher axial compressive loadings, making it an ideal solution for jacking pipe applications. Although they vary in design and application, both methods produce a corrosion resistant pipe with superior strength and outstanding hydraulic properties.

Properties, dimensions and standards

  • Size Range: DN300 – DN4000
  • Pressure Range: PN1 – PN40
  • Lengths: up to 11.8m
  • Stiffness: SN1250 – SN20000 (Higher ratings for jacking pipes)
  • Product Range: Pipe, GRP manholes, tanks and an extensive range of fabricated fittings



DN PIPE OD ID KG/M ID KG/M ID KG/M
PN1, PN6 & PN10 PN 16 PN25
300 345 333 13 333 14 334 14
375 426 411 17 412 18 412 20
450 507 489 26 490 30 492 28
525 587 566 41 568 33 569 35
600 667 644 50 646 47 647 46
675 747 721 64 723 58 724 57
750 826 797 70 800 72 800 71
900 924 891 103 894 91 897 86
1000 1026 990 128 994 112 996 106
1100 1126 1085 155 1089 135 1093 127
1200 1229 1185 183 1190 161 1193 151
1300 1331 1284 215 1289 188 1292 176
1400 1434 1382 249 1388 218 1392 204
1500 1536 1482 284 1488 250 1490 238
1600 1638 1581 324 1587 284 1589 271
1700 1740 1678 365 1685 319 1686 309
1800 1842 1777 409 1784 358
1900 1944 1875 455 1883 398
2000 2045 1973 503 1981 441
3000 3066 2956 1064 2968 931
4000 4085 3941 1883 3957 1596

Contact us for information on intermediate diameters, alternate stiffness and pressure classes.
