Unrestrained Mechanical Coupling

Unrestrained Mechanical Coupling

Our range of unrestrained mechanical couplings comply with AS/NSZ 4998 for potable and non-potable water applications.

The Clover unrestrained mechanical coupling range is suitable for connecting and repairing cold water piping systems.

  • Three bolt coupling design up to DN150 for fast field installation.

  • Can be installed without disassembling which makes installation quick and simple.

  • Captive bolt head for one spanner operation, simplifying field assembly.

  • Certified to AS/NSZ 4998.

Overview

Our high strength 316 stainless steel mechanical couplings join a wide range of pipe materials and can be used to join pipes with equal or differing outside diameters (Up to 27mm). This makes the coupling ideal for joining PVC-O, PVC-M, PVC-U, GRP, ductile iron, asbestos cement, and steel.

While this product is manufactured with a lightweight 316 Stainless Steel barrel and fasteners, and feature wedge shape EPDM Seals, it is not recommended for use on polyethylene pipe.

Properties, dimensions and standards

  • Size Range: DN80 – DN600.
  • Allowable Operating Pressure: 1600kPa.
  • Maximum Temperature: 60 C.
  • Certifications: AS/NZS 4998:2009 & AS/NZS 4020.
  • Product Licence: OMK30060.
  • WSAA Appraisal: PA1728.

Long series

DNRangeA (Barrel)LM# BoltsNominal Setting GapMaximum Deflection Each End OCode
8088-1031762702163203DGVPC080
100108-1321762702433203DGVPC100
150158-1821762703043253DGVPC150
200214-2381762853535353DGVPC200
225242-2691762853975353DGVPC225
250270-2951762854176353DGVPC250
300330-3562163404816353DGVPC300
375400-4292163405658353DGVPC375
450488-51221634063610351.5DGVPC450
500540-56521634070312351.5DGVPC500
600656-68021634081814351.5DGVPC600



Short series

DNRangeA (Barrel)LM# BoltsNominal Setting GapMaximum Deflection Each End OCode
8088-1031012102163203DGVPC080SB
100108-1321212102433203DGVPC100SB
150158-1821362103043253DGVPC150SB

All fasteners supplied as M16. All dimensions are quoted in millimeters.
