Resilient Seat Gate Valve

Resilient Seat Gate Valve

Clover's resilient seated gate valves comply with AS 2638.2 for use in applications across water supply and sewerage.

Our range of resilient seated gate valves are designed to be high strength and impact resistant.

  • Suitable for above and below ground potable, non potable and wastewater applications.

  • High strength 431 Stainless steel spindle provides excellent corrosion resistance.

  • Thermally bonded polymeric coating for long life corrosion protection.

  • Isolated stainless steel fasteners for corrosion protection.

Overview

Our range is manufactured from ductile iron and EPDM encapsulated gate, with their full bore design eliminating any potential build up of debris.

Clover’s resilient seated gate valve is cast in foot design for stability and safe and easy storage with fixed lifting devices for simple installation.

Properties, dimensions and standards

  • Size Range: DN50 – DN750
  • Allowable Operating Pressure: 1600kPa
  • Maximum Temperature: 40 C
  • Connections: Socket, Spigot and Flange AS4087 and AS2129
  • Certifications: AS 2638.2 and AS/NZS 4020
  • Product License: OMK25731
  • WSAA Appraisal: PA11/21



Item Part Name Material
1 Body Ductile iron AS1831 Fusion coat AS4158
2 Gate Ductile iron AS1831 EPDM Encapsulated
3 Stem Nut Aluminium Bronze
4 Spindle 431 Stainless Steel
5 Body Gasket EPDM AS1646
6 Bonnet Ductile iron AS1831 Fusion coat AS4158
7 Body Bolt 316 Stainless Steel
8 Thrust Washer POM
9 Thrust Collar DN50-300 POM.  DN375+ Alum. Bronze
10 Bonnet Bolt 316 Stainless Steel
11 O Ring NBR AS1646
12 Seal Kit EPDM AS1646
13 Dust Cover EPDM AS1646
14 Seal Retainer 316 Stainless Steel
15 Key Cap Ductile Iron Fusion Coat AS4158
16 Pipe Seal EPDM AS1646
