TOM PVC-O Pipe

Make Enquiry

TOM PVC-O Pipe

Overview

Clover has the most technically advanced manufacturing process for Oriented PVC pipe (PVC-O), for use in potable, recycled and sewer applications. The orientation process imparts high strength and maximum material efficiency. It is the most eco-friendly pipe system in the world, as it requires less energy to produce than conventional PVC and other pipe materials. In fact, it has the lowest embodied energy of any pipe system.

Other high performance pipe systems in our PVC range include PVC-M and PVC-U options, for both pressure and non-pressure applications.

Product Standards: AS/NZS4441, AS4441

Key Features

  • New Generation Series 2 PVC-O Pipe
  • Sizes from DN100 to DN600
  • Pressures from PN12 to PN25
  • Stiffness >SN10000 minimum
  • High Strength, Light Weight
  • Eliminates corrosion and electrolysis
  • High impact resistance
  • Increased hydraulic capacity
  • Fatigue resistance
  • 100% Australian owned
  • 100% Recyclable

Applications & Features

Applications

  • Water supply reticulation and trunk mains
  • Irrigation systems
  • Recycled water systems
  • Pumped Effluent – Sewage, Industrial & waste water
  • Slurry pipelines – mining waste
  • Potable water applications (Blue pipe)
  • Recycled Water applications (Purple pipe)
  • Pressure Sewer applications (Cream pipe)

Features

  • Exceptional Strength and Ductility
  • High Impact Resistance
  • Larger Bore – Better flow characteristics
  • Smooth Bore – Low flow resistance
  • Corrosion Resistant
  • Guaranteed Stiffness of SN12,000 (DN100 – DN300), SN10,000 (DN375 – DN600)
  • Light Weight – Installation savings
  • Material & Energy efficient – 100% Recyclable
  • Low Embodied Energy

Product Range

TOM PVC-O Pipe – Series 2 (RRJ)

DNOD
(mm)
Length
(mm)
Mean ID (mm)Pack
Qty
PN16
Class 450
PN16
Class 500
PN25
Class 500
1001226 m114.9112.336
1501776 m167.3163.524
2002326 m219.1214.110
2252596 m244.7239.18
2502866 m270.0263.86
3003456 m325.9318.56
3754266 m404.7393.110 *
4505076 m481.7467.76 *
6006676 m633.9615.56 *

* Packs can be altered to suit project and transport needs.
